Importing from files in GMNS format

Before importing a network from a source in GMNS format, it is imperative to know in which spatial reference its geometries (links and nodes) were created. If the SRID is different than 4326, it must be passed as an input using the argument ‘srid’.

As of July 2022, it is possible to import the following files from a GMNS source:

• link table;

• node table;

• use_group table;

• geometry table.

You can find the specification for all these tables in the GMNS documentation, here.

By default, the method create_from_gmns() read all required and optional fields specified in the GMNS link and node tables specification. If you need it to read any additional fields as well, you have to modify the AequilibraE parameters as shown in the example. When adding a new field to be read in the parameters.yml file, it is important to keep the “required” key set to False, since you will always be adding a non-required field. Required fields for a specific table are only those defined in the GMNS specification.

Note

In the AequilibraE nodes table, if a node is to be identified as a centroid, its ‘is_centroid’ field has to be set to 1. However, this is not part of the GMNS specification. Thus, if you want a node to be identified as a centroid during the import process, in the GMNS node table you have to set the field ‘node_type’ equals to ‘centroid’.
